Metal Oxide Leaded Film Resistor 插件式金屬氧化皮膜電阻

MOF

0.1Ω~22MΩ

±1%,±2%,±5%

200

0623/0932/1145 1550/1765/2485

Features

特征

一Excellent Long-Time stability一High surge / overload capability—Wide resistance range : 0.1Q~10MQControlled temperature coefficient

一優良的長時間穩定性一高浪涌/過載能力寬電阻范圍：0.1q~10 mq控制溫度系數

Resistance standard tolerance: 15%(consult factory for ±2%,1%)—Electrical and mechanical stability and high reliability

電阻標準公差：15%(參考工廠的±2%，1%)-機電穩定性和高可靠性

Applications

應用

Automotive

汽車

-Telecommunication—Medical Equipment

-電信-醫療設備
